Sensing Input of AVR 12A : Voltage 180~260VAC,1phase2wire
² Power Input for Voltage Regulator 12A: Voltage 180~260VAC,1phase2wire
² Output of AVR GAVR-12A: Voltage Max.90VDC@240VACinput
² Current of Voltage Regulator AVR-12A: Continuous 4A
² Intermittent 7A for 10SEE.
² Resistance Min.12 Max.100
² Voltage Build-up: Residual volts at AVR terminal>5VAC
² External Volts Adjustment: 7%with 1K 1watt trimmer
² Soft Start Ramp Time: 2sec.
² Unit Power Dissipation: Max.8Watt
² EMI Suppression: Internal Electromagnetic Interference Filtering
² Thermal. Drift: 0.03%per change in AVR ambient
² Under Frequency Protection: 60Hz system presets knee point at 55Hz
² (Factory Settings) : 50Hz system presets knee point at 45Hz
Other Replacement AVR Models Also Available:
AS480, AVC63-4, AVC63-4A, EA04C, EA05A, EA05AF, EA08A, EA15A, EA16A, EA350, EA440-T, EP200, GAVR-8A, GAVR-12A, GAVR-20A, GAVR-75A, GB110, GB15A, GB120, GB130, GB160, GB170, M16FA655A, MX321, MX341, MX450, R220, R230, R250, R438, R448, R450, SE350, SR7, STL-F, SX440, SX460, UVR6, VR6, WT-2, WT-3 ETC.
Please do not hesitate to contact us for any help!
