| Products Technical Specifications for Small Air Cool Diesel Engine Models from WSEPO | ||||||||||||||
| Model | WSE170F | WSE173F | WSE178F/FS | WSE186F/FS | WSE186FA | WSE188F/FS | WSE192F/FS | |||||||
| Type | Single-cylinder, vertical,4-stroke,air-cooled diesel engine | |||||||||||||
| Combustion system | Direct injection | |||||||||||||
| Bore×stroke(mm) | 70×55 | 73×59 | 78×62 | 86×70 | 86×72 | 88×75 | 92×75 | |||||||
| Displacement(cc) | 211 | 247 | 296 | 406 | 418 | 456 | 499 | |||||||
| Speed(rpm) | 3600 | 3600 | 3600 | 3600 | 3600 | 3600 | 3600 | |||||||
| Max. output(kw/hp) | (3.1)4.2 | (3.5)5.0 | (4.4)6.0 | (6.6)9.0 | (6.8)10 | (7.8)11.0 | (8.5)12.0 | |||||||
| Cont. output(kw/hp) | (2.8)3.8 | (3.2)4.7 | (4.0)5.4 | (6.3)8.6 | (6.5)8.8 | (7.5)10.2 | (8.0)11.0 | |||||||
| Starting system | Recoil or Electric(Optional) | |||||||||||||
| Power output method | Crankshaft / Camshaft (The speed of camshaft is 1/2 of the Crankshaft’s) | |||||||||||||
| Rotary direction of output axis | Counter Clockwise(View in the direction of output axis)/ Clockwise for FS Model | |||||||||||||
| Fuel/lubrication(L) | 0# in summer,-10# or -20# in winter light diesel fuel/SAE 10W30 | |||||||||||||
| Fuel capacity(L) | 2.5 | 2.5 | 3.5 | 5.5 | ||||||||||
| Lubrication capacity(L) | 0.75 | 0.75 | 1.1 | 1.65 | ||||||||||
| Recommended starting system | 12V-18AH | 12V-18AH | 12V-24AH | 12V-35AH | ||||||||||
| Net Weight(kg) | 27 | 33 | 48 | |||||||||||
| Engine Dimensions | 332×376×415 | 383×421×445 | 417×441×494 | |||||||||||
| (L×W×H)mm | ||||||||||||||
