Model |
ET95 / ET95-ES |
ET110 / ET110-ES |
ET120 / ET120-ES |
ET140DI / ET140DI-ES |
Type |
Water-Cooled, 4-Stroke, Horizontal, Diesel Engine |
No of Cylinder (unit) |
1 |
Cylinder Bore x Stroke (mm x mm) |
86 x90 |
92 x90 |
94 x90 |
97 x96 |
Displacement Volume (cc) |
522 |
598 |
624 |
709 |
Maximum Power hp/rpm (kW/rpm) |
9.5/2400(6.99/2400) |
11/2400(8.09/2400) |
12/2400(8.8/2400) |
14/2400(10.3/2400) |
Continuons Rated Power hp/rpm (kW/rpm) |
8.5/2400(6.25/2400) |
10/2400(7.35/2400) |
11/2400(8.09/2400) |
12.5/2400(9.19/2400) |
Sepcific Fuel Consumption at Continuons Rated Power g/kWh( g/hph ) |
≦286 ( 210 ) |
≦257 ( 188 ) |
Compression Ratio |
21:1 |
18:1 |
Valve Clearance (mm) |
0.195-0.235 |
Max torque (kgf.m/rpm) |
29.4/1600 |
34.5/1600 |
38.2/1600 |
50/1600 |
Cooling Water Capacity (L) |
2.1 |
Fuel Tank Capacity (L) |
11 |
Lubrication Oil Capacity (L) |
2.8 |
Fuel |
Light Diesel Oil (SAE No.2-D) |
Lubrication Oil |
SAE 40 API CF |
Combustion System |
Swril Chamber |
Direct Injection |
Cooling system |
Pressurized Radiator type |
Lubricating system |
Trochoid Pump |
Air Cleaner Type |
Wet-Type (Oil Bath - Type) |
Starting System |
Double Speed Hand Starting / The ES Model Feature an Electric Starter |
Direction of Rotation |
Clockwise as Viewed from The Starting Handle (Right Hand Rotation) |
Battery (ES Model Only) |
12 Volt Battery (Minimum 30 amperes- hour/Ah) |
N.W(kg) |
105/110 |
110/115 |
112/117 |
116/121 |
Packing dimension(L*W*H) |
830*380*630mm |
