MODEL |
ZT80 |
ZT90 |
ZT95 |
ZT95-ES |
ZT100 |
ZT100 -ES |
ZT110 |
ZT110 -ES |
ZT120 |
ZT120 -ES |
ZT125DI |
ZT125DI-ES |
ZT140DI |
ZT140DI -ES |
ZT155DI |
ZT155DI -ES |
Type |
Water-Cooled, 4-Stroke, Horizontal, Diesel Engine |
No of Cylinder (unit) |
1 |
Cylinder Bore x Stroke (mm x mm) |
84 x84 |
86 x84 |
86 x90 |
88 x90 |
92 x90 |
94 x90 |
94 x96 |
97 x96 |
100 x98 |
Displacement Volume (cc) |
465 |
487 |
522 |
547 |
598 |
624 |
666 |
709 |
769 |
Maximum Power hp/rpm (kW/rpm) |
8/2400 (5.9/2400) |
9/2400 (6.6/2400) |
9.5/2400 (7/2400) |
10/2400 (7.4/2400) |
11/2400 (8.1/2400) |
12/2400 (8.82/2400) |
12.5/2400 (9.2/2400) |
14/2400 (10.3/2400) |
15.5/2400 (11.4/2400) |
Continuons Rated Power hp/rpm (kW/rpm) |
7/2400 (5.2/2400) |
8/2400 (5.9/2400) |
8.5/2400 (6.3/2400) |
9/2400 (6.6/2400) |
10/2400 (7.4/2400) |
11/2400 (8.1/2400) |
11/2400 (8.1/2400) |
12.5/2400 (9.2/2400) |
13.5/2400 (10/2400) |
Sepcific Fuel Consumption at Continuons Rated Power g/kWh( g/hph ) |
264(194) |
265(195) |
258 (190) |
271(199) |
264(194) |
267(196) |
234 ( 172 ) |
240 ( 176 ) |
Compression Ratio |
23:1 |
21:1 |
22:1 |
21:1 |
18:1 |
Valve Clearance (mm) |
0.16-0.20 |
0.195-0.235 |
Max torque (kgf.m/rpm) |
2.8/1600 |
3.0/1600 |
3.1/1600 |
3.4/1600 |
3.8/1600 |
4.0/1600 |
4.7/1600 |
5.0/1600 |
5.3/1600 |
Cooling Water Capacity (L) |
1.6 |
2.1 |
Fuel Tank Capacity (L) |
10 |
11 |
Lubrication Oil Capacity (L) |
2.4 |
2.8 |
Fuel |
Light Diesel Oil (SAE No.2-D) |
Lubrication Oil |
SAE 40 API CF |
Combustion System |
Swril Chamber |
Direct Injection |
Cooling system |
Pressurized Radiator type |
Lubricating system |
Trochoid Pump |
Air Cleaner Type |
Wet-Type (Oil Bath - Type) |
Starting System |
Double Speed Hand Starting / The ES Model Feature an Electric Starter |
Direction of Rotation |
Clockwise as Viewed from The Starting Handle (Right Hand Rotation) |
Battery (ES Model Only) |
12 Volt Battery (Minimum 30 amperes- hour/Ah) |
N.W.(kg) |
88 |
88 |
98 |
105 |
103 |
110 |
108 |
110 |
109 |
111 |
109 |
111 |
110 |
112 |
110 |
112 |
G.W.(kg) |
103 |
103 |
113 |
120 |
118 |
125 |
123 |
125 |
123 |
126 |
123 |
126 |
125 |
127 |
125 |
127 |
Packing dimension(L*W*H) |
890*410*630mm |
Container Loading (20'GP/40'HQ) |
100/275 |
100/275 |
100/230 |
100/220 |
100/230 |
100/220 |
100/220 |
100/215 |
100/220 |
100/215 |
100/220 |
100/215 |
100/220 |
100/215 |
100/220 |
100/215 |
