| MODEL | ZT80 | ZT90 | ZT95 | ZT95-ES | ZT100 | ZT100 -ES |
ZT110 | ZT110 -ES |
ZT120 | ZT120 -ES |
ZT125DI | ZT125DI-ES | ZT140DI | ZT140DI -ES |
ZT155DI | ZT155DI -ES |
| Type | Water-Cooled, 4-Stroke, Horizontal, Diesel Engine | |||||||||||||||
| No of Cylinder (unit) | 1 | |||||||||||||||
| Cylinder Bore x Stroke (mm x mm) | 84 x84 | 86 x84 | 86 x90 | 88 x90 | 92 x90 | 94 x90 | 94 x96 | 97 x96 | 100 x98 | |||||||
| Displacement Volume (cc) | 465 | 487 | 522 | 547 | 598 | 624 | 666 | 709 | 769 | |||||||
| Maximum Power hp/rpm (kW/rpm) |
8/2400 (5.9/2400) |
9/2400 (6.6/2400) |
9.5/2400 (7/2400) |
10/2400 (7.4/2400) |
11/2400 (8.1/2400) |
12/2400 (8.82/2400) |
12.5/2400 (9.2/2400) |
14/2400 (10.3/2400) |
15.5/2400 (11.4/2400) |
|||||||
| Continuons Rated Power hp/rpm (kW/rpm) |
7/2400 (5.2/2400) |
8/2400 (5.9/2400) |
8.5/2400 (6.3/2400) |
9/2400 (6.6/2400) |
10/2400 (7.4/2400) |
11/2400 (8.1/2400) |
11/2400 (8.1/2400) |
12.5/2400 (9.2/2400) |
13.5/2400 (10/2400) |
|||||||
| Sepcific Fuel Consumption at Continuons Rated Power g/kWh( g/hph ) |
264(194) | 265(195) | 258 (190) | 271(199) | 264(194) | 267(196) | 234 ( 172 ) | 240 ( 176 ) | ||||||||
| Compression Ratio | 23:1 | 21:1 | 22:1 | 21:1 | 18:1 | |||||||||||
| Valve Clearance (mm) | 0.16-0.20 | 0.195-0.235 | ||||||||||||||
| Max torque (kgf.m/rpm) | 2.8/1600 | 3.0/1600 | 3.1/1600 | 3.4/1600 | 3.8/1600 | 4.0/1600 | 4.7/1600 | 5.0/1600 | 5.3/1600 | |||||||
| Cooling Water Capacity (L) | 1.6 | 2.1 | ||||||||||||||
| Fuel Tank Capacity (L) | 10 | 11 | ||||||||||||||
| Lubrication Oil Capacity (L) | 2.4 | 2.8 | ||||||||||||||
| Fuel | Light Diesel Oil (SAE No.2-D) | |||||||||||||||
| Lubrication Oil | SAE 40 API CF | |||||||||||||||
| Combustion System | Swril Chamber | Direct Injection | ||||||||||||||
| Cooling system | Pressurized Radiator type | |||||||||||||||
| Lubricating system | Trochoid Pump | |||||||||||||||
| Air Cleaner Type | Wet-Type (Oil Bath - Type) | |||||||||||||||
| Starting System | Double Speed Hand Starting / The ES Model Feature an Electric Starter | |||||||||||||||
| Direction of Rotation | Clockwise as Viewed from The Starting Handle (Right Hand Rotation) | |||||||||||||||
| Battery (ES Model Only) | 12 Volt Battery (Minimum 30 amperes- hour/Ah) | |||||||||||||||
| N.W.(kg) | 88 | 88 | 98 | 105 | 103 | 110 | 108 | 110 | 109 | 111 | 109 | 111 | 110 | 112 | 110 | 112 |
| G.W.(kg) | 103 | 103 | 113 | 120 | 118 | 125 | 123 | 125 | 123 | 126 | 123 | 126 | 125 | 127 | 125 | 127 |
| Packing dimension(L*W*H) | 890*410*630mm | |||||||||||||||
| Container Loading (20'GP/40'HQ) | 100/275 | 100/275 | 100/230 | 100/220 | 100/230 | 100/220 | 100/220 | 100/215 | 100/220 | 100/215 | 100/220 | 100/215 | 100/220 | 100/215 | 100/220 | 100/215 |
